Product Details
Attenuation High-Range
23 dBA
Attenuation Low-Range
16 dBA
Back Pressure High-Range
76 mm Hg (2.99 inch Hg)
Back Pressure Low-Range
25 mm Hg (0.98 inch Hg)
Back Pressure Mid-Range
51 mm Hg (2.01 inch Hg)
Body Diameter Maximum
255.5 mm (10.06 inch)
Body Length
1124 mm (44.25 inch)
Brand
DONALDSON
Country of Origin
United States
Dangerous Good
No
HTS Code
8708924963
Inlet Diameter
127.64 mm (5.03 inch)
Outlet Diameter
127.64 mm (5.03 inch)
Overall Length
1295.4 mm (51.00 inch)
Pieces Per Box
1
Pieces Per Pallet
16
Rated Flow High-Range
83.5 m³/min (2948.77 cfm)
Rated Flow Low-Range
49.9 m³/min (1762.20 cfm)
Rated Flow Medium-Range
70.6 m³/min (2493.22 cfm)
Style
Style 1
Unit
ea
UPC Code
742330161234
Package Information
Packaged Depth (cm)
134.9
Packaged Width (cm)
26.7
Packaged Height (cm)
26.7
Packaged Weight (kg)
14.76
