Product Details
Attenuation High-Range
20 dBA
Attenuation Low-Range
15 dBA
Back Pressure High-Range
76 mm Hg (2.99 inch Hg)
Back Pressure Low-Range
25 mm Hg (0.98 inch Hg)
Back Pressure Mid-Range
51 mm Hg (2.01 inch Hg)
Body Diameter Maximum
214.88 mm (8.46 inch)
Body Length
558.8 mm (22.00 inch)
Brand
DONALDSON
Country of Origin
United States
Dangerous Good
No
HTS Code
8708924963
Inlet Clock Position
6:00
Inlet Diameter
76.66 mm (3.02 inch)
Outlet Clock Position
12:00
Outlet Diameter
76.66 mm (3.02 inch)
Overall Length
596.9 mm (23.50 inch)
Pieces Per Box
1
Pieces Per Pallet
17
Rated Flow High-Range
30.8 m³/min (1087.69 cfm)
Rated Flow Low-Range
17.8 m³/min (628.60 cfm)
Rated Flow Medium-Range
25.1 m³/min (886.40 cfm)
Style
Style 5
Unit
ea
UPC Code
742330004999
Package Information
Packaged Depth (cm)
72.4
Packaged Width (cm)
22.9
Packaged Height (cm)
21.6
Packaged Weight (kg)
0.011
